Theia 2.0 Surgery Chair


Italian design and technology in the world

Brands: Gardhen Bilance

Categories: ,

  • Available in 2 versions, with high and low backrest.
  • Multifuncitonal surgery chair with high stability. It can be used for a wide range of surgical interventions.
  • Frame with a reduced footprint. It allows an easy approach to the device.
  • Extremely resistant base in stainless steel. Easy to sanitize with most commonly used detergents.
  • Lying surface in expanded foam with high density.
  • Seamless upholstery made out of carefully selected fabric with antibacterial, water resistant and non-toxic. Upholstery’s features as follows: antibacterial, flame retardant class 1IM, antimycotic, ecologic, latex free, phtalate free and resistant.
  • Minimum height (530 mm, minimum value compared to market standards) makes it easy for any patient to access even to people with reduced mobility.
  • Assisted egress position helping people with reduced mobility.
  • Independent movement for the best postural adjustment.
  • The armrests are synchornized with backrest’s movement. They can be rotated outward, overturned and removed.
  • No wear parts.
  • The device can be equipped with a wide range of accessories according to surgeon’s needs.
  • Anti-schock position.
  • H24 operativity without connection to the electrical grid.
  • Max load capacity 300kg
Standard features
  • Lying surface divided in 4 sections with double articulation divided in: headrest, backrest, seat and leg.
  • Motorized backrest.
  • Motorized legrest.
  • Height adjustble through motorized columns.
  • Motorized Trendelenburg.
  • Headrest available from the following: ACS1, ACS2, ACS3, ACS4, ACS4/1; pediatric models ACS1P, ACS2P, ACS3P are also available. In the absence of preferences the code ACS1 will be provided. All headrests are described and illustrated on p. 13.
  • Special coating without seams or interstices, made with carefully selected technological material with the following properties: water repellent, non-toxic, antibacterial, antifungal, antistatic, ecological, latex free, without phthalates. Ultra-resistant coating to: alcohol, hydrogen peroxide, sodium hypochlorite (5%), commonly used disinfectants, liquids and physiological substances. Fireproof eco-leather UNI 9175/87 and 9175FA-1/94 class 1M. (equipment code AC87 / 1).
  • Upholstery in black fabric (other colours available – download colours chart via QR code at the bottom of this page). Upholstery divided into 2 separate sections, one for the back section and the other for the seat / leg sections. The operating table is also available with a single seamless cover (accessory code ACS27).
  • Movements are entirely controlled by the control panel (standard equipment) and/or foot controls (accessory – see page 13).
  • Low voltage 4000N motors.
  • Multi-voltage power supply.
  • Bilateral multifunctional armrest.
  • Twin wheels diameter 100 mm with independent brake.
  • No.8 stainless steel DIN bars that can be equipped with a wide range of accessories.
  • Non- reflecting coating with thermosetting powders.
  • A dedicated software allows an easy handling of the movements.
  • Equipotential node.
  • No.2 rechargeable and removable batteries. They grant a h24 operativity to the device.
  • Charger included.
  • Knobs for transport located on the leg section.
Technical Sheet



Product ID


Intended use

Surgery chair



Total weight

120 kg

Type of control

Control panel


Stainless swivel 4 wheels Ø 150 mm with braking system


100 – 240 Vac 50/60 Hz

Battery power

24v – 4.5A

Electric motors

Low voltage 24 (Volt)

Max electrical input




Max load

300 kg

Safety working load

335 kg

Backrest angle


Legs angle



Download Theia 2.0 Surgery Chair Manual
